Línea A1 MM

Sellos de Semi Proceso

El sello mecánico VAZEL Línea "A1" mm, es utilizado en bombas industriales, turbinas rotativas, centrífugas o agitadores. Funciona con fluidos hidráulicos y soluciones acuosas, dependiendo la combinación de materiales.

Materiales

Material Asiento *

Material Cara *

Material Elastómero *

Partes Metálicas *

Material Resorte *

Diámetro de Eje

Cantidad

Dimensiones

A	B	C	D	E	K	L	M	N
15	31.75	23.8	34.11	30.94	7.92	33.32	8.74	10.31
16	31.75	23.8	34.11	30.94	7.92	33.32	8.74	10.31
18	34.93	26.97	37.29	34.11	9.53	33.32	8.74	10.31
19	34.93	26.97	37.29	34.11	9.53	33.32	8.74	10.31
20	36.91	27.96	39.27	34.11	9.53	33.32	8.74	10.31
22	38.1	30.15	42.06	38.89	9.53	34.93	8.74	10.31
24	41.28	33.32	44.45	41.28	9.53	39.67	9.53	11.13
25	41.28	33.32	44.45	41.28	9.53	39.67	9.53	11.13
26	44.45	36.5	47.5	44.32	9.53	41.28	9.53	11.13
28	44.45	36.5	47.5	44.32	9.53	41.28	9.53	11.13
30	47.63	39.67	50.8	47.63	9.53	41.28	9.53	11.13
32	47.63	39.67	50.8	47.63	9.53	41.28	9.53	11.13
33	50.8	42.85	53.98	50.8	9.53	42.85	9.53	11.13
35	50.8	42.85	53.98	50.8	9.53	42.85	9.53	11.13
38	55.6	47.65	59.8	50.8	9.53	45.2	9.53	11.13
40	60.33	50.8	63.5	60.33	9.53	50.8	11.13	12.7
42	60.33	50.8	63.5	60.33	9.53	50.8	11.13	12.7
43	60.33	50.8	63.5	60.33	9.53	50.8	11.13	12.7
45	63.5	53.98	66.68	63.5	9.53	50.8	11.13	12.7
48	66.68	57.15	69.85	66.68	9.53	53.98	11.13	12.7
50	69.85	60.33	73.02	69.85	9.53	53.98	11.13	12.7
52	76.2	63.5	76.2	76.2	12.7	60.33	12.7	14.27
55	76.2	63.5	76.2	76.2	12.7	60.33	12.7	14.27
56	76.2	63.5	76.2	76.2	12.7	60.33	12.7	14.27
58	76.2	63.5	76.2	76.2	12.7	63.5	12.7	14.27
60	82.55	69.85	82.55	82.55	12.7	63.5	12.7	14.27
63	85.73	73.02	85.73	85.73	12.7	63.5	12.7	14.27
65	88.9	76.2	88.9	88.9	12.7	69.85	12.7	14.27
68	88.9	79.38	98.43	92.08	12.7	69.85	14.27	15.88
70	88.9	79.38	98.43	92.08	12.7	69.85	14.27	15.88
75	98.43	85.73	106.73	103.17	12.7	73.03	14.27	15.88
