Línea AM

Sellos de Mono Resorte

El sello mecánico VAZEL Línea "AM", es utilizado en bombas industriales, turbinas rotativas, centrífugas o agitadores. Funciona con fluidos hidráulicos y soluciones acuosas, dependiendo la combinación de materiales.

Materiales

Material Asiento *

Material Cara *

Material Elastómero *

Partes Metálicas *

Material Resorte *

Diámetro de Eje

Cantidad

Dimensiones

A	B	C	D	E	K	M	N	L1	L2
10	22.23	15.88	26.97	23.8	7.92	6.35	7.92	30.18	20.62
11	25.4	19.05	30.15	26.97	7.92	6.35	7.92	30.18	20.62
12	25.4	19.05	30.15	26.97	7.92	6.35	7.92	30.18	20.62
13	25.4	19.05	30.15	26.97	7.92	6.35	7.92	30.18	20.62
14	25.4	19.05	30.15	26.97	7.92	6.35	7.92	30.18	20.62
15	31.75	23.8	34.15	30.94	7.92	8.74	10.31	33.32	22.22
16	31.75	23.8	34.11	30.94	7.92	8.74	10.31	33.32	22.22
18	34.93	26.97	37.29	34.11	9.53	8.74	10.31	33.32	22.22
19	34.93	26.97	37.29	34.11	9.53	8.74	10.31	33.32	22.22
20	34.93	26.97	37.29	34.11	9.53	8.74	10.31	33.32	22.22
22	38.1	30.15	42.06	38.89	9.53	8.74	10.31	34.93	23.8
24	41.28	33.32	44.45	41.28	9.53	9.53	11.13	39.67	25.4
25	41.28	33.32	44.45	41.28	9.53	9.53	11.13	39.67	25.4
26	44.45	36.5	47.5	44.32	9.53	9.53	11.13	41.28	26.97
28	44.45	36.5	47.5	44.32	9.53	9.53	11.13	41.28	26.97
30	47.63	39.67	50.8	47.63	9.53	9.53	11.13	41.28	26.97
32	47.63	39.67	50.8	47.63	9.53	9.53	11.13	41.28	26.97
33	50.8	42.85	53.98	50.8	9.53	9.53	11.13	42.85	28.58
35	50.8	42.85	53.98	50.8	9.53	9.53	11.13	42.85	28.58
38	53.98	46.02	57.15	53.98	9.53	9.53	11.13	42.85	28.58
40	60.33	50.8	63.5	60.33	9.53	11.13	12.7	50.8	34.93
42	60.33	50.8	63.5	60.33	9.53	11.13	12.7	50.8	34.93
43	63.5	53.98	66.68	63.5	9.53	11.13	12.7	50.8	34.93
45	63.5	53.98	66.68	63.5	9.53	11.13	12.7	50.8	34.93
48	66.68	57.15	69.85	66.68	9.53	11.13	12.7	53.98	38.1
50	69.85	60.33	74.6	71.42	9.53	11.13	12.7	53.98	38.1
52	76.2	63.5	79.38	76.2	12.7	12.7	14.3	60.33	42.85
53	76.2	63.5	79.38	76.2	12.7	12.7	14.3	60.33	42.85
55	76.2	63.5	79.38	76.2	12.7	12.7	14.3	60.33	42.85
58	82.55	69.85	85.73	82.55	12.7	12.7	14.3	63.5	46.02
60	82.55	69.85	85.73	82.55	12.7	12.7	14.3	63.5	46.02
63	85.73	73.03	88.9	85.73	12.7	14.27	15.88	63.5	46.02
65	85.73	73.03	95.25	92.08	12.7	14.27	15.88	69.85	49.2
68	88.9	79.38	98.43	95.25	12.7	14.27	15.88	69.85	49.2
70	88.9	79.38	98.43	95.25	12.7	14.27	15.88	69.85	49.2
75	98.43	85.73	106.35	103.17	12.7	14.27	15.88	73.03	52.37
